Agora Cloud Recording generates M3U8 index files and TS/WebM slice files after a recording. To process the recorded files, such as merging the audio and video files, or synchronizing the playback with other stream files, you need to know the naming conventions of the recorded files, how to parse the information in the M3U8 file, and when slicing occurs.
In individual recording mode, the naming conventions are as follows:
<sid>: Recording ID
<cname>: Channel name
<uid>: User ID
<type>: File type,
<utc>: The UTC time when the slice file starts. The time zone is UTC+0, and the timestamp consists of the year, month, day, hour, minute, second, and millisecond. When
20190611073246073, for example, the slice file starts at 07:32:46.073 a.m., June 11, 2019.
In the file name
sid713476478245 is the recording ID,
cnameagora is the channel name,
123 is the user ID, and the start time of the recording is 12:51:42.485 a.m., September 20, 2019.
In composite recording mode, the naming conventions are as follows:
- M3U8 files:
- TS files:
<sid>is the recording ID;
<cname>is the channel name;
<utc>is the starting time (UTC) of the TS file. The time zone is UTC+0. The timestamp consists of the year, month, day, hour, minute, second, and millisecond. For example, if
20190611073246073, the starting time of the TS file is 07:32:46.073 a.m., June 11, 2019.
Recorded files in abnormal conditions
When uploading files to the third-party cloud storage fails
If Agora Cloud Recording fails to upload the recorded files to the third-party cloud storage, it transfers the files to the third-party cloud storage from the Agora Cloud Backup. In order not to overwrite the latest files, the transferred M3U8 file is appended with
<tick>: Related to the time when the index file is generated.
<n>: The index of the M3U8 file.
0. The higher the index, the newer the version of the file.
Taking the file name of
sid713476478245_cnameagora__uid_s_123__uid_e_video_22194679897_3.m3u8 as an example, the "
3" at the end indicates that this is the fourth version of the M3U8 file.
When you find transferred M3U8 file(s) in the third-party cloud storage, compare the M3U8 file taking the highest index with the file without a suffix, and choose the one holding more content records.
The cloud recording service does not append the suffix to the names of the TS/WebM files.
When a server is disconnected or the process killed
When a cloud recording server is disconnected or the process killed, the cloud recording service enables the high availability mechanism, where the fault processing center automatically switches to a new server within 90 seconds to resume the service. Each time the service enables the high availability mechanism, it creates a new M3U8 file, which contains the index information of the recorded slice files from the time when the service resumes. The file name is prepended with
n stands for the number of times the mechanism is enabled in a recording, and starts off with
Taking the file name of
bak0_sid713476478245_cnameagora.m3u8 as an example,
bak0 indicates that this file is generated after the service enables the high availability mechanism for the first time.
After the cloud recording service enables the high availability mechanism, the names of the recorded TS/WebM files are also prepended with
The M3U8 file contains the file names of several slice files and descriptive symbols. The M3U8 file generated by Agora Cloud Recording has three descriptive symbols:
#EXT-X-AGORA-TRACK-EVENT:EVENT=<event>,TRACK_TYPE=<type>,TIME=<utc>: The first slice file after a stream starts or restarts after an interruption has this descriptive symbol, which describes the state of the stream.
EVENT: Name of the event. Currently,
EVENTcan only be
START, which means that the stream has started or restarted after an interruption.
TRACK_TYPE: The content of the slice file,
TIME: Time when the state of the stream changes.
TIMEis in UTC and the time zone is UTC+0.
#EXT-X-AGORA-ROTATE:WIDTH=<width>,HEIGHT=<height>,ROTATE=<rotate>,TIME=<utc>: The first slice file after a video rotates has this descriptive symbol, which describes the details of the rotation. A slice file may have several such symbols.
WIDTH: Width of the video.
HEIGHT: Height of the video.
ROTATE: The degrees by which the video rotates anticlockwise.
ROTATEcan only be
TIME: The time when the video rotates.
TIMEis in UTC and the time zone is UTC+0.
#EXTINF:<length>: Length of the slice file in seconds.
#EXT-X-AGORA-ROTATE:WIDTH=640,HEIGHT=480,ROTATE=90,TIME=20190920125142485 #EXT-X-AGORA-TRACK-EVENT:EVENT=START,TRACK_TYPE=VIDEO,TIME=20190920125142485 #EXTINF:6.332000 sid713476478245_cnameagora__uid_s_123__uid_e_video_20190920125142485.ts
The sample M3U8 file above contains the file name of a TS file and three descriptive symbols, which indicates that the TS file is the first slice file after the video stream starts or restarts after an interruption, the video rotates by 90 degrees anticlockwise, and the TS file lasts for 6.332 seconds.
Video file slicing
Slicing occurs when any of the following conditions is met:
- When an I frame appears and the slice file reaches 15 seconds.
- The codec changes.
- The width or height of the video changes.
- The video stream is interrupted.
- When you set the browser to use H.264 codec for encoding, forced slicing occurs when the slice file reaches 5.5 minutes, or the file size is over 50 MB. After forced slicing, the first frame of the new slice file might not be an I frame, in which case the slice file cannot be decoded and played directly. For example, in the communication channel, sometimes only one I frame may appear in several hours. In such case, the first frame of the new slice file is probably not an I frame.
When you set the browser to use VP8 codec, Agora Cloud Recording will not force slicing the file.
Audio file slicing
Slicing occurs when an I frame appears and the slice file reaches 15 seconds.
Sample M3U8 file for audio
#EXTM3U #EXT-X-VERSION:3 #EXT-X-MEDIA-SEQUENCE:0 #EXT-X-ALLOW-CACHE:YES #EXT-X-TARGETDURATION:18 #EXT-X-DISCONTINUITY #EXT-X-AGORA-TRACK-EVENT:EVENT=START,TRACK_TYPE=AUDIO,TIME=20190920125142289 #EXTINF:15.019000 sid713476478245_cnameagora__uid_s_123__uid_e_audio_20190920125142289.ts #EXTINF:15.019000 sid713476478245_cnameagora__uid_s_123__uid_e_audio_20190920125157307.ts #EXTINF:15.019000 sid713476478245_cnameagora__uid_s_123__uid_e_audio_20190920125212326.ts #EXTINF:15.019000 sid713476478245_cnameagora__uid_s_123__uid_e_audio_20190920125227345.ts #EXTINF:12.523000 sid713476478245_cnameagora__uid_s_123__uid_e_audio_20190920125242363.ts #EXT-X-ENDLIST
Sample M3U8 file for video
#EXTM3U #EXT-X-VERSION:3 #EXT-X-MEDIA-SEQUENCE:0 #EXT-X-ALLOW-CACHE:YES #EXT-X-TARGETDURATION:18 #EXT-X-DISCONTINUITY #EXT-X-AGORA-ROTATE:WIDTH=640,HEIGHT=480,ROTATE=0,TIME=20190920125142485 #EXT-X-AGORA-TRACK-EVENT:EVENT=START,TRACK_TYPE=VIDEO,TIME=20190920125142485 #EXTINF:6.332000 sid713476478245_cnameagora__uid_s_123__uid_e_video_20190920125142485.ts #EXT-X-AGORA-ROTATE:WIDTH=1280,HEIGHT=720,ROTATE=0,TIME=20190920125149174 #EXT-X-DISCONTINUITY #EXTINF:17.442000 sid713476478245_cnameagora__uid_s_123__uid_e_video_20190920125149174.ts #EXT-X-DISCONTINUITY #EXT-X-AGORA-ROTATE:WIDTH=640,HEIGHT=480,ROTATE=0,TIME=20190920125206616 #EXTINF:33.326000 sid713476478245_cnameagora__uid_s_123__uid_e_video_20190920125206616.ts #EXT-X-DISCONTINUITY #EXT-X-AGORA-ROTATE:WIDTH=1280,HEIGHT=720,ROTATE=0,TIME=20190920125239942 #EXTINF:14.815000 sid713476478245_cnameagora__uid_s_123__uid_e_video_20190920125239942.ts #EXT-X-ENDLIST
